S235JR Single Layer Grid Space Frame Truss Prefabricated GB Roof

  • 1
  • 2

Brand Name : Jiangsu Andy steel structure

Model Number : Q235

Place of Origin : Jiangsu

MOQ : 100 Square Meters

Price : US55-75 Square Meters

Payment Terms : T/T, L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 100 Ton/days

Delivery Time : 21-30 Days

Packaging Details : 40ft

Product : steel space frame roof structure

Material : Q235

Color : Customized

Packaged : wood package

life : 50-70 years

large span : 100-300 meters

application : structural roofing

processing service : Bending,Welding,decoiling,cutting,punching

Purlin : C.Z Shape Steel Channel

Tolerance : ±1%

Contact Now

Simple Installation Prefabricated Design Space Frame

Description

  • Single layer grid: All elements are located on the surface to be approximated.
  • Double layer grid: Elements are organized in two layers parallel to each other at a certain distance apart. Each of the layers form a lattice of triangles, squares or hexagons in which the projection of the nodes in a layer may overlap or be displaced relative to each other. Diagonal bars connect the nodes of both layers in different directions in space. In this type of meshes, the elements are associated into three groups: upper cordon, cordon and cordon lower diagonal.
  • Triple layer grid: Elements are placed in three parallel layers, linked by the diagonals. They are almost always flat.

Feature

Space frames are sometimes used in the chassis designs of automobiles and motorcycles. In both a space frame and a tube-frame chassis, the suspension, engine, and body panels are attached to a skeletal frame of tubes, and the body panels have little or no structural function. By contrast, in a unibody or monocoque design, the body serves as part of the structure.

Brand name space frame coal storage shed yard in steel structure construction
Model 1.Single slope, Double slope, Multi-slope.
2.Single span, Double-span, Multi-span, Single floor, Double floors.
Column and beam 1.Material Q345(S355JR)or Q235(S235JR) steel.
2.All bolts connecting.
3.Straight cross-section or Variable cross-section.
Fabrication Advanced Automatic Welding Machines
Quality control GB/T19001-2000----ISO9001:2000
Surface Hot-dip galvanized or painted
Roof and wall panel 1.EPS ,PU ,Rockwool sandwich panel.
2.Single colorful corrugated steel sheet0.326~0.8mm thick, YX28-205-820(820mm wide).
3.Sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~150mm, 950mm or 960mm width.
Carrying capacity 1.Resisting winds and seismic impacts.
2.Bearing heavy snows.
Drawing 1.Making the design and quotation according to your requirements very soon.
2.Making the quotation according to your drawings.
3.Giving you the satisfying opinion to your project.

S235JR Single Layer Grid Space Frame Truss Prefabricated GB Roof

Why the space frame structure stand out?

The flexibility and rigidity of space frame structure are immensely growing and in coming days will soon captivate the markets. Its aesthetics and design outlook makes it a worthy option. Apart from the pointers discussed above, in a series of upcoming article we will discuss on several other specifications and advantages of a Space Frame Structure.

1. Who we are?
We are a global one-stop manufacturer of steel structure solutions. We can offer the service from good design to installation with good quality.
2.Factory or trade company?
We are factory, so the factory competitive price will be offered.Our factory covers an area of 360,000 square meters.Our production capacity is 150000 tons per year.
3. Quality assurance and guarantee?
Established a procedure to check products at all stages of the manufacturing process-raw materials. in process materials. validated or tested materialsfinishedoods.etc.
If there is one quality problems in one project.5%contract amount will be returned
4. Do you offer quiding installation on site overseas?
Yes. we can povide the service of installation.We can send our professional technical enaineer and teams to offer the installation on site overseas.
